About: DS18 SB12A 12" 350W RMS Loaded Amplified Shallow Subwoofer Enclosure
For all audio enthusiasts who demand exceptional sound but have limited space, DS18 offers the perfect solution. Introducing the DS18 SB12A, a slim 12-inch subwoofer enclosed in a compact sealed box, designed to bring earth-shattering bass to even the tightest of spaces. With the SB12A, DS18 has engineered a subwoofer that defies all expectations, delivering powerful, chest-thumping bass in a compact enclosure that fits seamlessly into any vehicle.
Housed in a rugged .6-inch MDF sealed box, the SB12A is built to withstand the rigors of everyday use while maintaining optimum sound quality. The included high-powered amplifier, boasting 350W RMS and a staggering 700W MAX, ensures that every beat hits with precision and intensity.
The enclosure housing the SB12A has an internal volume of 16 liters (0.56 ft3), allowing this subwoofer to strike the perfect balance between compactness and performance. The SB12A delivers an impressive frequency response ranging from 30Hz to 250Hz, ensuring rich and deep bass notes that resonate through your vehicle.
Safety and protection features are at the core of the SB12A's design. Thermal protection safeguards against overheating, while over-load, DC output, and short circuit protection provide peace of mind during high-performance audio sessions. The remote level control, selectable crossover, and a bass boost range of 0-6 dB at 50Hz allows you to fine-tune the bass according to your preferences; effortlessly transforming your driving experience into a concert on wheels.
The SB12A offers versatile connectivity options, providing high-level inputs or RCA jacks to seamlessly integrate with any existing audio system. Simply hook it up, sit back, and let the bass take control.
Product Highlights:
Subwoofer Enclosure
1 X 12" Shallow Mount
Amplified with Subwoofer Control Knob
RMS Power: 350 Watts (700 Watts Peak)
Impedance: 2 Ohm ~ 87dB
1/2" MDF with Black Carpet
Specifications:
Speaker Type / Size: 12" (312 mm)
Total Impedance: 2 Ohm
Total RMS Power Handling: 350W
Total MAX Power Handling: 700W
Sensitivity (1w/1m): 87dB
Frequency Response: 30-250Hz
Voice Coil Diameter: 1.75" (44.43 mm)
Voice Coil Former Material: Aluminum
Winding Material: EISV
Cone Material: IPP
Dust Cap Material: N/A
Surround Material: Rubber
Basket Material: SPCC
Magnet Material: Ferrite
Magnet Weight: 50 Oz
Amplifier Specifications:
Amplifier Class: Digital
Amplifier Type: Monoblock Subwoofer
Number of Channels: 1CH
Minimum Impedance: 2 Ohm
Signal to Noise Ratio: 75 dB
Efficiency @ 4ohm: 75%
Total Harmonic Distortion (THD): 0.30%
Low Level Input Range: 0.1-0.6 V
High Level Input: Yes
Selectable X-Over: LPF Fixed
X-Over Filter Range: 51 - 200 Hz
Bass Boost Range: 0-6 dB
Bass Boost Frequency: 50 Hz
Infrasonic Filter: No
Phase Selector: 0-180
Led Indicator: Power / Protection
Power Input Terminal Size: 8 Ga
Fuse Size: 30 A
Remote Level Control: Yes
Cooling Fan: No
Voltmeter: No
Thermal Protection: Yes
Over-Load Protection: Yes
DC Output Protection: Yes
Short Circuit Output Protection: Yes
Voltage Input Protection: Yes (16v)
Clipping Protection: No
Box Specifications:
Internal Volume: 16L / 0.56ft3
Port Tune Fb: N/A
Load Configuration: Parallel in
Box Type: Sealed Box
Box Material: 0.59" MDF
Finish Material: NON-Woven fabric
-3Db Dropping Point F3: 45Hz
Measurement:
Height: 14.96" (380 mm)
Width: 19.3" (490 mm)
Depth 1: 4.92" (125 mm)
Depth 2: 7.4" (188 mm)
Gross Single Unit Weight: 18.7 lb (8.5 kg)
Single Unit Box Dimensions (W x L x H): 546mm x 245mm x 440mm
