Roland's KC amps are known for their powerful high-fidelity sound, onboard mixing features, versatile connectivity, and lasting durability. The latest generation carries on the time-honored KC benchmark of quality while offering new enhancements tuned for the needs of today's working musicians.
The 50-watt KC-80 is a miniature powerhouse with three line input channels, a dedicated aux input, and support for an XLR vocal mic. Compared to the previous-generation KC-60, the power section has been completely redesigned for higher output, better stability, and enhanced bass reproduction. In addition, the 10-inch woofer has been upgraded for improved sound quality. If desired, the low-end performance can be extended by driving a powered subwoofer from the KC-80's Sub Out jack.
Features
Compact and affordable keyboard amplifier with 50 watts of power
Redesigned power amp and power supply sections provide increased stability and improved bass reproduction
Custom two-way speaker system with newly developed 10-inch woofer and tweeter
Onboard mixing with three 1/4-inch input channels, dedicated auxiliary input with 1/8-inch and RCA jacks, and master EQ
XLR mic input, 1/4-inch line output, headphones output, and sub output
Metal jacks for increased durability
Specifications
Rated Power Output: 50 W
Nominal Input Level (1 kHz):
CH1 (MIC/LINE): -50 - -20 dBu
CH2 (LINE): -20 dBu
CH3 (LINE): -20 dBu
AUX IN (L, R, STEREO): -10 dBu
Nominal Output Level (1 kHz):
LINE OUT:+4 dBu
SUB OUT:+4 dBu
Speakers: 25 cm (10 inches) Woofer x 1, Tweeter x 1
Controls:
POWER switch
[CH1] MIC/LINE knob
[CH2] LINE knob
[CH3] LINE knob
[EQUALIZER] LOW knob, HIGH knob
MASTER knob
Indicator: Power
Connectors:
CH1 jack: XLR type
CH1 (MIC/LINE) jack: 1/4-inch phone type
CH2 (LINE) jack: 1/4-inch phone type
CH3 (LINE) jack: 1/4-inch phone type
AUX IN (L, R) jacks: RCA phono type
AUX IN (STEREO) jack: Stereo miniature phone type
LINE OUT jack: 1/4-inch phone type
SUB OUT jack: 1/4-inch phone type
PHONES jack: 1/4-inch TRS phone type (mono signal output)
Power Consumption: 50 W
Dimensions (W x D x H): 420 x 300 x 410 mm (16-9/16 x 11-13/16 x 16-3/16 inches)
Weight: 12.5 kg (27 lbs 9 oz)
