7049 200 Amp Panel Mount 187 Series Circuit BreakerFeatures:Combines switching and circuit protection into a single device*Clear, single lever operation"Trip Free" design cannot be held "ON" during fault current conditionWaterproofRecessed mounting holes for clean appearanceLarge Clearance around terminal studs accecpt heavy gauge wire l

Blue Sea 7049 200 Amp Panel Mount 187 Series Circuit Breaker

Model: CW40597
Web Code: 12543504
Sold and shipped by | 4.1 seller rating (311 reviews)

Available for deliveryAvailable online only

Delivery times vary by location. Most Marketplace items leave sellers' locations within 2 business days. Allow additional time for shipping.

Enjoy on orders from this seller.

Seller Return Policy

Warranty

Check with the manufacturer for details.

For Quebec residents: See the Availability Guarantee disclosure in the Specifications section below.

7049 200 Amp Panel Mount 187 Series Circuit BreakerFeatures:

Combines switching and circuit protection into a single device*

Clear, single lever operation

"Trip Free" design cannot be held "ON" during fault current condition

Waterproof

Recessed mounting holes for clean appearance

Large Clearance around terminal studs accecpt heavy gauge wire lugs

Robust 5/16 M8 terminals provide high torque connections

Large lever with vertical/horizontal orientation provides indication of trip status

Ignition protected - Safe for installation aboard gasoline powered boats

Specifications:

Interrupt Rating - 5,000 A@12V DC, 3,000A@24V DC, 1,500A@42V DC

Maximum Voltage Rating - 48 Volts DC

Operating Temperature Range - -40xC to 85xC

Circuit Breaker Type - Thermally responsive bi-metal blade

Circuit Breaker Class - Type III - switchable/manual reset - trip free

Terminal Stud Size - 5/16"-18

Terminal Stud Torque - 75 in-lb

Mounting Holes - Accept #10 (M5) Screw

Weight Lb (Kg) - 0.50 (0.23)

Case Material - Thermoset Polyester

Product : BLUE SEA 7049 200 AMP PANEL MOUNT CIRCUIT BREAKER Manufacturer : BLUE SEA SYSTEMS Manufacturer Part No : 7049 UPC : 632085070496
