About: DS18 NXL-8/BK NXL 8" 2-Way Coaxial Marine Speaker With LED RGB Lights 125W RMS - Black
DS18’s NXL-8/BK are not only designed to deliver breathtaking sound quality but also to withstand the harshest marine and off-road conditions. DS18’s NXL-8/BK boasts a sleek and rugged design that not only catches the eye but also performs like a champion. Crafted for durability and performance, these speakers feature IP65 Marine Grade Compliant Specifications, making them resistant to the corrosive effects of saltwater, UV rays, and extreme temperatures. The high temp injection-molded composite construction guarantees resilience against the most demanding conditions, while the ASA grills with UV coating ensure long-lasting aesthetics.
The NXL-8/BK can handle an impressive 125W of RMS power, giving you the volume and clarity you crave. Equipped with Y35 Ferrite Main Magnet and Reverse Neodymium, these speakers deliver astonishingly clear and powerful sound. Thanks to the NXL-8’s revolutionary 2-way design that incorporates a 25mm Titanium Dome Tweeter, you'll experience the full range of frequencies, capturing every nuance of your favorite tracks. The NXL-8’s sensitivity of 93dB at 1 w/m, will leave you astounded by the level of detail and precision in every note.
These models of DS18’s HYDRO NXL-8/BK speakers immerse you in a world of vivid color with the integrated RGB LED lighting. DS18 has left no detail overlooked, allowing you to customize your audio system to match your mood or style. With the optional DS18 LED-BTC or any other RF/BT/Wi-Fi Controller (sold separately), you have full control over the multi-function RGB LED lighting, daring you to create a showstopping system.
Product Highlights:
8" 2-Way Marine Speaker
RMS Power: 125 Watts
Impedance: 4 Ohm
Ferrite & Neodymium Magnets
RGB LED Light
Water Resistant IP65
Specifications:
Nominal Diameter: 8" (203 mm)
Nominal Impedance: 4 Ohm
RMS Power Handling: 125W
MAX Power Handling: 375W
Sensitivity (1w/1m): 93dB
Frequency Response: 35Hz-23KHz
Recommended HI Pass Crossover: 50 Hz
Body / Features:
UV Compliant: Yes, 100% Stable
Marine Grade Type: IP65
RGB LED: Yes, RGB integrated
Grill Type: Injection Molded Composite ASA with UV Protection coating
Color / Finish: Matte Black
Sold as a Pair
Woofer Specifications:
Voice Coil Diameter: 1.2" (30.5 mm)
Voice Coil Former Material: Kapton
Winding Material: CCAW
Cone Material: Injection Molded Polypropylene + UV Compliant
Surround Material: Butyl (Rubber)
Basket Material: High Temp Injection Molded Composite with UV Protection coating
Magnet Material: Ferrite + Neodymium
Magnet Weight: 24oz + 0.32oz
Tweeter Specifications:
Nominal Diameter: 1" (25.4 mm)
Voice Coil Diameter: 1" (25.4 mm)
Voice Coil Former Material: Kapton
Winding Material: CCAW
Diaphragm Material: Titanium + PEI Surround
Magnet Material: Neodymium (N38H)
Magnet Weight: 0.54oz
Thiele & Small Parameters:
Equivalent Volume (Vas): 66.7L / 2.35ft3
Excursion (one way) Xmax: 8.5 mm
Free Air Resonance (Fs): 56Hz
Mechanical Factor (Qms): 7.701
Electrical Factor (Qes): 0.899
Total Factor (Qts): 0.805
Moving Mass (Mms): 7.265g
Compliance (Cms): 1.119mm/N
Bl Factor (Bl): 2.98
Voice Coil Inductance (Le): 0.49mH
Cone Area (Sd): 206.12cm2
DC Resistance (Re): 3.15 ohms
Efficiency Bandwidth Product (EBP): 62.2
Measurements:
Overall Diameter: 8.59" (218.2 mm)
Overall Depth: 4.45" (113 mm)
Front Mount Baffle Cutout: 6.97" (177 mm)
Mounting Depth: 3.09" (78.5 mm)
Motor Diameter: 4.32" (110 mm)
Gross Single Unit Weight: 10.5 lb
Single Unit Box Dimensions (W x L x H): 20.25" x 10.25" x 5.5"
