The Security Power Supply Module is fully supervised for AC failure, low battery, and AUX failure, providing up to 1 Amp @ 12 VDC. It is compatible with HS2016, HS2032, HS2064, and HS2128 control panels.

DSC Security Power Supply Module, High Current PGM Expander

Model: HSM2300
Web Code: 18170211
Sold and shipped by | 3.0 seller rating (4 reviews)

Available for deliveryAvailable online only

Delivery times vary by location. Most Marketplace items leave sellers' locations within 2 business days. Allow additional time for shipping.

Seller Return Policy

Warranty

Check with the manufacturer for details.

For Quebec residents: See the Availability Guarantee disclosure in the Specifications section below.

• The HSM2300 is a supervised power supply that can be used to power any PowerSeries Neo (Corbus) module or +12 VDC sensor

• Connect up to 4 modules per system

• Hardwired zone expansions allows for easy expansion of zones and programmable outputs

• Fully supervised expansion ensures constant communication with PowerSeries Neo control panel

• Tamper supervision available, ensuring product is always secure

• Connects to control panel via 4-wire Corbus

• Simple wiring can be home run, daisy chained or tee-tapped anywhere on the Corbus

• Fully encrypted communications back to PowerSeries Neo

**

Board Current Draw: ................................................ 40 mA (Max)

Voltage ...............................................................12 VDC Nominal

Aux Output......................................................................1 A Max

Transformer Secondary Ratings:............................16.5Vac, 40VA

Battery Capacity:......................4Ah, 7Ah, or 14Ah (2 x 7Ah) max.

Operating Environment:.................-10°C to 55°C (14°F to 131°F)

Relative Humidity:.......................................................... 5 to 93%

Product Condition
Brand New

Dimension

Width (Inches)
5.7 in
Height (Inches)
3.27 in
