Ui packs a complete digital mixing system into a compact, road-rugged stagebox format, with built-in Wi-fi and the ability to be controlled by any connected device via a standard web browser - no Apps, no OS limitations, no constraints on how or where you mix. Ui is safe, simple and secure, empowering you to be able to mix easily from anywhere in the venue and supercharge your live sound with powerful digital mix features and dedicated processing from some of the biggest names in the business - dbx, Lexicon and Digitech.
Key Features:
* Tablet/PC/Smartphone Controlled Digital Mixer
* Integrated Wi-Fi
* Cross-platform compatibility with iOS, Android, Windows, Mac OS, and Linux devices
* Use up to 10 control devices (tablets, phones, PCs) simultaneously
* Legendary Harman Signal Processing from dbx, Digitech, and Lexicon
* Fully recallable and remote-controlled mic preamps
* 4-band Parametric EQ, High-Pass Filter, Compressor, De-esser and Noise Gate on input channels
* 31-band Graphic EQ, Noise Gate and Compressor on all outputs
Real-Time Frequency Analyser (RTA) on inputs and outputs
* 3 dedicated Lexicon FX effects processors: Reverb, Delay and Chorus
* Subgroups, Mute Groups, View Groups, and more mixer controls
* Show/Snapshot recall with channel safes and security lockout
Powerful digital mix features
Every input on Ui features full channel processing to get a great sound on any vocal or instrument, including a 4-band Parametric EQ, High-Pass Filter, Compressor, De-esser and Noise Gate. Outputs feature a 31-band Graphic EQ, dbx AFS2 Advanced Feedback Suppression, Noise Gate and Compressor. There's also a full complement of all the mixer functions you'd expect - including subgroups, mute groups and view groups.
Save the perfect settings for every song
With Ui's Snapshot recall system, you can create the perfect mix for a show, or even individual songs, and save the settings to be recalled at will. Need a subdued, effects-laden mix for the acoustic ballad? No problem, just call it up. Then hit recall to load in the settings for the full-tilt rock number that follows it up.
Uncompromised connectivity
Ui hardware is loaded with all the connectivity you'll need to run the show. XLR mic and combo inputs with fully recallable and remote controlled mic pre's, stereo RCA inputs and dedicated Hi-Z inputs, optimised for acoustic guitars, electric guitars and basses. Outputs include balanced XLR and 1/4" main outs, XLR Aux outs and headphone connectivity. There's even USB connectivity for 2-channel playback and recording direct to USB storage devices (recording on Ui16 only).
Specifications:
Hardware Form: Floor
Wi-Fi Router Onboard: Yes
Ethernet control: Yes
Total Inputs: 12
XLR Mic Inputs: 4 Mic/Line, 4 Mic
Hi-Z/instrument channels: 2
Main Outputs: XLR and 1/4"
Aux / Monitor Sends: 2 balanced XLR
USB Playback: 2-channel
USB Stereo Recording: No
HDMI Output: No
Headphone 1/4" Out: 2
Stereo RCA Line input: Yes
Dimensions (HxWxL): 85mm x 177mm x 320mm (3.3 x 7.0 x 12.6 inches)
Weight: 2.29 kg (5 lbs)
