High-quality compact studio monitors for the uncompromising creator
HS Series speakers are the standard in studio monitors, trusted for many years by the world's top audio engineers, producers, and artists. Now Yamaha has redefined their essence in a compact housing. The HS4 is a powerful tool to help create a wide range of audio content-from music production to video editingthat meets the expectations of creators who have limited space but do not want to compromise on monitoring quality.
Sound that's always true to the original
The H34 studio monitors embody Yamaha's legacy of design excellence. No detall has been overlooked. Inside are carefully selected parts such as a high-performance class-D amplifler, a highly resilient MDF cabinet, as well as woofers and soft-dome tweeters that deliver a pure sound faithful to the source - despite their small aize. Additionally, Yamaha's proprietary "Twisted Mare Port technology delivers crystal-clear beas with minimal turbulence noise, The result is outstanding resolation, sound image, and depth with a flat response across all bandwidths without any coloring of the original sound.
Optimal sound tailored to your environment
The sound produced by speakers can sometimes be affected by the surrounding environment.
The rear panel of the HS4 is equipped with ROOM CONTROL and HIGH TRIM functions that allow you to make adjustments to achieve the ideal sound for any environment, such as reducing the unneeded, exaggerated low-end that can often occur when speakers are placed next to walls.
Inputs and controls to fit any use
The rear panel of the HS4 is equipped with combination XLR/TRS phone, RCA, and stereo mini connectors, allowing you to connect to a wide range of equipment such as computers, audio interfaces, audio mixers, and electric instruments. The most commonly used features-power button, volume knob, and headphone connector-are located in the front for easy access.
Compact and portable
The compact size of the HS4 was made possible thanks to the highly efficient class-D amp. Using one amp for two speakers has enabled us to both reduce the weight of the speakers and simplify the cable connections. They take up little space even in a small bedroom studio, and are easy to take with you on the road.
High-quality compact studio monitors for the uncompromising creator
Features* 2-way bass-reflex powered speaker with 4.5" cone woofer and 1" dome tweeter
* 60 Hz - 22 kHz frequency response (-10 dB)
* 26 W + 26 W output power (Dynamic, RL=6 Ω)
* ROOM CONTROL and HIGH TRIM response controls
* XLR/TRS Phone (COMBO), RCA, and Stereo Mini inputs
* Stereo mini - RCA cable, speaker cable, and anti-slip pad included
SpecifcationsSpeaker Type: 2-way powered speaker, Bass-reflex type
Frequency response (-10dB): 60 Hz - 22 kHz
Frequency response (-3dB): 83 Hz - 20 kHz
Crossover: 2.3 kHz
Maximum Output Level (Measured peak, IEC noise@1m): 102 dB SPL
Components
HF: 1" Dome
LF: 4.5" Cone
Nominal impedance: 6 Ω
I/O connectors: [Input Connector] L Side: COMBO (XLR/TRS Phone) x2, RCA x2, Stereo Mini, R Side: Speaker Input; [Output Connector] L Side: Headphone, Speaker Output
Output power: 26 W + 26 W (Dynamic, RL=6 Ω), 20 W + 20 W (THD 0.1%, 1kHz, RL=6 Ω)
Input sensitivity: LINE 1 (COMBO): +4 dBu, LINE 2 (RCA, ST Mini): -10 dBu (Volume: Maximum)
Input Level: LINE 1 (COMBO): +20 dBu, LINE 2 (RCA, ST Mini): +6 dBu (Maximum Input)
Input impedance: LINE 1 (COMBO): 20 kΩ, LINE 2 (RCA, ST Mini): 10 kΩ
Controls: Front: Volume, Rear: ROOM CONTROL SWITCH (0/-2/-4 dB under 500 Hz), HIGH TRIM SWITCH (+2/0/-2 dB above 2 kHz)
Indicators: Power ON (White LED)
Power requirements: Depending on area of purchase; 100-240 V, 50/60 Hz
Power consumption: 15 W
Cabinet material: MDF
Dimensions
Width: L Side: 150 mm (5.9"), R Side: 150 mm (5.9")
Height: L Side: 240 mm (9.4"), R Side: 240 mm (9.4")
Depth: L Side: 213 mm (8.4"), R Side: 203 mm (8.0")
Net weight: L Side: 3.7 kg (8.2 lb), R Side: 3.1 kg (6.8 lb)
Accessories: Stereo Mini - RCA Cable 1.5 m, Speaker Cable 2.5 m, Anti Slip Pad, Quick Start Guide, Safety Guide
