The 8-note polyphonic Virtual Analog reface CS has five unique oscillator modules for an incredible variety of sounds from analog to digital, 4 effects, integrated phrase looper, continuous input for volume control, MIDI connectivity, aux input, and dual line outputs.
Features:
* Analog Physical Modeling Engine with multiple synthesis and oscillator types. Each oscillator type has flexible LFO and ADSR routing plus unique Texture and Mod controls.
* Onboard effects processor with five types add depth to your sound.
* 8-note polyphony allows complex chords and pads or switch to mono Mode for fat synth bass or solo leads.
* 37 HQ (High Quality) Mini Keys provide premium feel and response for fast, accurate and natural playing.
* 2W 3cm stereo speaker system lets you play any place, any time
* Specially designed bass reflex port technology enhances bass response for full, rich sound
* Battery powered - uses six "AA" batteries with five hours of life
* USB "TO HOST" allows MIDI connectivity to your USB-equipped computer or iOS device
* Dual 1/4"unbalanced line outputs provide connection to mixers, audio interfaces, DI boxes and more
* A 3.5mm aux line input lets you connect and hear mobile devices, tablets and more through the instrument
Specs:
VOICES
5 OSC types: Multi-saw, Pulse, Oscillator Sync, Ring Modulation, Frequency Modulation
Effects:
- OFF (effect bypass,)
- Delay
- VCM Phaser
- VCM Chorus/Flanger
- Distortion
KEYBOARD
- 37 keys HQ mini (High-Quality mini)
- Initial Touch
TONE GENERATION
- Maximum Polyphony: 8
- Engine: AN (Analog Physical Modeling)
- Amplifiers: 2 W x 2
- Speakers: 3 cm x 2
CONNECTIVITY
- DC IN: DC IN (12 V) jack
- Headphones: PHONES (6.3 mm, stereo phone jack)
- MIDI: MIDI (mini-DIN IN/OUT)
- AUX IN: AUX IN (3.5 mm, mini stereo phone jack)
- OUTPUT: L/MONO, R (6.3 mm, TS phone jack, unbalanced)
- USB TO HOST: USB (TO HOST)
- Pedal Type: FOOT CONTROLLER: FC7 (sold separately) to adjust the volume
POWER SUPPLY
- Power Consumption: 6 W (When using PA-130 power adaptor)
- Battery Life: Approximately 5 hours
- Auto Power Off: Yes
Power Supply:
- Adaptors - PA-130 or an equivalent recommended by Yamaha (sold separately)
- Batteries: Six AA size batteries or Ni-MH rechargeable batteries
ACCESSORIES
- Included: MIDI breakout cable, Owner's Manual
SIZE/WEIGHT
Dimensions:
- Width: 530 mm (20 7/8")
- Height: 60 mm (2 3/8")
- Depth: 175 mm (6 7/8")
Weight:
- 1.9 kg (4 lbs, 3 oz) (not including batteries)
