axGear POE Network Switch 16 Port POE 100M + 2 Port 1000M Uplink + 1 Port 1000M SFP

POE Network Switch 16 Port POE 100M + 2 Port 1000M Uplink + 1 Port 1000M SFP The 16+2+1 port Ethernet switch provides non-blocking, wire speed switching for your 10/100M  network.

Widely used in wireless AP, IP phone, camera, wireless bridge, alarm, network hard disk player, monitor display, wireless router, network print server, etc.

The Ethernet Switch was designed for easy installation and high performance in an environment where traffic on the network and the number of users increase continuously.

Applicable for: small and medium-sized office networks, Every port has independent bandwidth.

It not only can realize the data transmission function of common switches but also can supply power to network terminals at the same time.

  Can supply power to wireless AP and IP camera

16 port: 10/100 Mbps auto-sensing RJ45 ports

2 port: 10/100/1000 Mbps auto-sensing RJ45 ports

1 port: 10/100/1000 Mbps Auto-sensing SFP optical fiber port (Option)

Total POE power: 200W (port 1 to port 16)

Maximum power per port ups to 30W

Support anti-thunder to port (AC power port: Differential mode +/-2kv, common mode +/-4kv)

POE power supply: 1,2(+)/3,6(-) (Default); 45(+),78(-) (Option)

Switch Mode: 3 modes.

Mode 1: port 1-16 10/100M auto-sensing. @100 meters;

Mode 2: port 17-18 1000M @100 meters;

Mode 3: port 19 1000M SFP optical fiber @20 km (Option)

Package included:

1 x 16+2+1 POE Switch

1 x Power Cord

1 x Manual
