LG 43UH5N-E UHD Signage Display
UHD Signage Display with LG webOS Platform and Advanced Security | High Resolution Display
It offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.
Convenient webOS Platform
The UH5N-E is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.
Durability that Provides Reliability
Optimized for business environments, the UH5N-E is protected against salt, dust, iron powder and humidity thanks to conformal coating on power board, allowing for stable operation. Also, its customer-centric features, such as IP5x, 30-degree tilting and Shock Monitoring, provide both reliability and satisfaction.
Design for Space Utilization
Designed with thin bezels and simple cable management, the UH5N-E saves space. With specialized hidden power inlets, it can be installed close to the wall, leaving only about 13 mm of space with the slim bracket. Bezels accessories can also be used to convert it into an art frame, making it a stylish interior element that matches customers' interior spaces.
Enhanced Security Features
The UH5N-E provides security features, including LG's Enhanced Kernel Protection (EKP) technology, protecting important data from external access or attacks. LG UHD Signage also holds reliable certification in the field of information security, maintaining customers' data and businesses securely. For example, this model is ISO/IEC 15408 Common Criteria EAL2 Certified.
Sustainability
With a commitment to innovation and sustainability, LG is continuously striving to create a better future for manufacturers, consumers, and future generations. With a focus on minimizing waste, maximizing recycling, and efficient power management, LG actively strives for sustainability, obtaining various certifications such as FCC EMC Class B.
SuperSign Solutions
SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
All Spec
DISPLAY
Size: 43 inch
Resolution: 3840 x 2160
Panel Type: IPS
Aspect Ratio: 16:9
Brightness (Typ.): 500 cd/m²
Contrast Ratio (Typ.): 1000:1
Color gamut: BT709 95%
Color Depth: 10bit(D), 1.07Billion colors
Response Time: Tr : 8ms / Tf :10ms
Refresh Rate (Max.): 60hz
Viewing Angle (CR≥10): 178º(H) / 178º(V)
Surface Treatment(Haze): 28%
Operation Hours (Hours/Day): 24/7
FEATURES
Internal Memory 16 GB
Built-in Wi-Fi
Temperature Sensor
Auto Brightness sensor
Acceleration(Gyro) Sensor
Local Key Operation
Speaker (Built-in)
webOS6.0
Local Contents Scheduling
Group Manager
USB Plug & Play
RS232C Sync
Local Network Sync
PIP (4)
PBP(4)
Screen Share
Video Tag (4)
Play via URL
Screen Rotation
External Input Rotation
Gapless Playback
Tile Mode SettinG(Max. 15x15)
Setting Data Cloning
SNMP
ISM Method
Auto Set ID
Status Mailing
Control Manager
Cisco Certi.
Crestron Inside
Smart Energy Saving
PM mode
Wake on LAN
Beacon
Network Ready
HDMI-CEC
SI Server Setting
webRTC
Pro:Idiom
CONNECTIVITY
3 x HDMI IN (3840x2160@60Hz, HDCP 2.2/1.4)
1 x DP IN (3840x2160@60Hz, HDCP2.2/1.3)
1 x RS232C IN( 4pin Phone-jack)
1 x RJ45(LAN) IN
1 x IR IN
1 x USB IN(USB2.0 Type A)
1 x HDMI Out (3840x2160@30Hz, Input : HDMI1/2/3/DP
1 x Audio Out
1 x RS232C Out(4pin Phone-jack)
Support Daisy Chain (Input HDMI, DP / Output HDMI)
POWER
Type: Built-In Power
AC Input: 100-240V (50/60Hz)
Power Consumption (Typ.): 80W
Power Consumption (Stand-by): 0.5W
Certification
Safety: CB / NRTL
EMC: FCC Class "B" / CE / KC
ErP / Energy Star: Yes (NewErP) / Yes
ePEAT(US only): Yes
ISTA6: Yes(~'23.9, US Suffix Only)
Carbon Trust: Yes(TBD, Reducing CO2)
BS476 Part7: Class 1 (case top / back cover)
EN13501-1: Class A1 (case top) / Class A2 (back cover)
Language
OSD: English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Turkish→Türkiye, Arabic
DIMENSIONS/WEIGHTS
Dimension with Stand (W x H x D): N/A
Dimension without Stand (W x H x D): 963.0 x 556.2 x 29.7mm (without IR)
Dimension in Shipping (W x H x D): 1055.0 x 660.0 x 142.0mm
Weight with Stand: N/A
Weight without Stand: 11.1kg
Weight in Shipping: 12.8kg
