MTX THUNDER 1000-Watt RMS Mono Block Class D Amplifier

MTX THUNDER..A name synonymous with car audio for over 20 years has become known for power, performance, and reliability. The THUNDER line of amplifiers has seen numerous technological advancements throughout its life and continues to be one of the most recognized and sought after products in the car audio world today.

The MTX THUNDER1000.1 mono block amplifier is the product of many of those advancements making it perfect for that “Bass in your face” attitude without taking up all of your valuable space.

FEATURES:

• Compact Design - The small footprint chassis allows for installation in space challenged vehicles

• Extruded Aluminum Heat Sink - The custom heat sink design maximizes heat transfer away from the circuitry protecting the amplifier

• Selectable Bass Boost - Selectable 0, 6, or 12dB bass boost centered @ 50Hz

• Variable Butterworth Crossover - a 12dB/Oct crossover that allows you to set the frequency your speakers will play down or up to

• Variable Subsonic Filter - A variable low frequency, high pass filter designed to block potentially damaging bass frequencies

• Triple Protection Circuitry - Thermal, DC Offset, and Short Circuit Protection circuitry ensures the amplifier will protect itself in the event of a problem

• Surface Mount PCB Design - Decreases chassis size, improves layout efficiency and increases vibration resistance without sacrificing performance or sound.

SPECIFICATIONS:

• Description: Mono Block

• Topology: Class D

• 4Ω RMS Power Output: 350W x 1 Channel

• 2Ω RMS Power Output: 600W x 1 Channel

• 1Ω RMS Power Output: 1000W x 1 Channel

• THD: Less Than 1%

• Signal to Noise Ratio: 80dB

• Frequency Response: 10Hz - 220Hz

• Crossover: Variable Low @ 40Hz to 220Hz, 12dB/Oct

• Subsonic Filter: 10Hz to 50Hz, 12dB/Oct Variable

• Bass Boost: 0-6-12dB Switchable

• Max Sensitivity: 200mV

• Maximum Input Signal: 5V

• Height: 6.3"

• Width: 12.13"

• Depth: 2.25"
