•Always-on, space-saving solution with ultra-narrow bezels
See an immersive and dependable viewing experience, 24/7 with Samsung’s VMT-U series. The slim depth and 500 nit brightness ensures highly visible images and messaging in various environments from shopping malls to lobbies, meeting rooms to control rooms and many more applications.
•Transform your space with high impact visuals
The slender design and 69.9mm* cabinet depth provides flexibility for installation. An extremely narrow 1.8mm bezel-to-bezel width creates a near seamless picture opening, while creating a captivating visual experience.
•View content from just about any angle
Wide viewing angles mean content is easily visible even if viewers aren’t standing directly in front of the display. Audiences can get clear details and vivid colours without having to be right in front of it.
•Vibrant images in almost any light
Non-glare panels evenly distribute light across the screen to maintain vibrant and accurate content. Combined with a high contrast ratio , visuals are vivid and eye-catching any time of the day or night.
•Image enhancement
Samsung’s powerful picture enhancement technology ensures all content is vibrant and clear. With Picture Enhancer mode, colour saturation and contrast are improved by adjusting the gamma curve. Using Black Equalizer mode, dark images are lightened, making details easier to see.
•Comprehensive calibration to fit your needs
Multi-step factory tuning provides uniform brightness and colour. Users can also fine-tune advanced settings with free powerful color Expert Pro software. For quick and simple calibration, color Expert Pro Mobile enables white balance adjustments for displays up to 5x5 using a mobile camera on a smartphone.
•Advanced presentation, simplified operation
Utilizing daisy chain design through DisplayPort 1.2 or HDMI ports enables the display to present UHD content on multiple screens without an external graphic card. Samsung's UHD Signage Player Box* streamlines functionality by combining the media player and content management software.
•Durable and user-friendly design
IP5x certified*, the VMT-U series is dust-resistant and able to withstand a range of environmental conditions without requiring an additional enclosure in dusty places. An embedded, centrally located infrared receiver (IR) allows for easier and more flexible user control to the display.
•Rigorous testing, robust protection
VMT-U series is delivered in specialized packaging which has passed a rigorous 4-step test to meet ISTA standards*, ensuring the display is protected from any potential damage during transit. This provides peace of mind for businesses that the display is ready to function immediately after delivery.
Diagonal Size: 46"
Panel Type: Direct LED
Resolution: 1,920 x 1,080
Pixel Pitch (HxV): 0.53 x 0.53
Brightness: MAX 500 cd/㎡
Contrast Ratio: 1,200 : 1
Viewing Angle (H/V): 178 / 178
Response Time: 8 ms
Color Gamut: 72 %
Glass Haze: 0.25 %
H-Scanning Frequency: 62.7 ~ 72.3 kHz
Maximum Pixel Frequency: 82 MHz
V-Scanning Frequency: 57 ~ 63 Hz
Dynamic Contrast Ratio: 45,000 : 1
HDMI In: 2
DP In: 1
DVI In: 1
USB: 1
Component In: No
Composite In: No
IR In: Yes
HDBaseT In: No
Audio In: Yes
Audio Out: Stereo Mini Jack
Video Out: Yes
Power Out: No
RS232 In: Yes
RS232 Out: Stereo Mini Jack
RJ45 In: Yes
RJ45 Out: No
Power Supply: AC 100 to 240 VAC (60 / 50 Hz)
Power Consumption (On Mode): 176 W
Power Consumption (Sleep Mode): 0.5 W
Set Dimension (WxHxD): 1022 x 69.9 x 577 mm
Package Dimension (WxHxD) (mm): 1193 x 719 x 257 mm
Set Weight: 15.7 kg
Package Weight: 22.2 kg
Temperature: 0℃ ~ 40℃
Humidity: 10 ~ 90 %
Bezel Width: 2.25 mm(U/L), 1.25 mm(R/B)
Frame Material: Glossy
External Memory Slot: No
Mount: Yes
Stand: No
MagicInfo Daisychain Videowall Support: Yes
Energy Efficiency Class: N/A
EMC: Class A
Safety: 60950-1
