Specifications
·
Mfr Part Number: RS3618XS
·
Hardware:
·
CPU: Intel Xeon D-1521 Quad Core 2.4 (base) up to 2.7 (turbo) GHz Hardware Encryption Engine (AES-NI)
·
Memory: 8GB DDR4 ECC UDIMM (expandable up to 64GB)
·
Drive Bays: 12x 3.5" or 2.5" SATA HDD/SSD
·
Max Internal raw Capacity: 144 TB (12x 12 TB drive) (Capacity may vary by RAID types)
·
External ports: 2x USB 3.0 Ports, 2x Expansion Ports
·
LAN: 2x RJ-45 1GbE LAN Port (with Link Aggregation / Failover support)
·
PCIe Expansion: 2x 3.0 x8 slots (x8 link)
·
Fan: 4x (80 x 80mm) Fans
·Easy Replacement System Fan
·Power Recovery
·
Noise Level: 50.2 dB(A)
·Scheduled Power On/Off
·Wake on LAN/WAN
·
Power Supply Unit/Adapter: 500W
·
AC Input Power Voltage: 100 - 240V AC
·
Power Frequency: 50/60 Hz, Single Phase
·
Networking Protocols: CIFS, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN)
·
File System:
·
Internal Drives: Btrfs, EXT4
·
External Drives: Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT
·
Storage management:
·
Maximum internal volume: 1024
·
Maximum iSCSI target: 64
·
Maximum iSCSI LUN: 512
·
File sharing capability:
·
Maximum user account: 16000
·
Maximum group: 512
·
Maximum shared folder: 512
·
Maximum Shared Folder Sync Tasks: 16
·
Maximum Concurrent CIFS/AFP/FTP Connections: 2048
·
Security: Firewall, encrypted shared folder, SMB encryption, FTP over SSL/TLS, SFTP, rsync over SSH, login auto block, Let's Encrypt support, HTTPS (Customizable cipher suite)
·
Utilities: Synology Assistant
·
Supported browsers: Chrome, Firefox, Internet Explorer 10 onwards, Safari 10 onwards, Safari (iOS 10 onwards), Chrome (Android 6.0 onwards)
·
Applications:
·
File Station: Virtual drive, remote folder, Windows ACL editor, compressing/extracting archived files, bandwidth control for specific users or groups, creating sharing links, transfer logs
·
Backup solutions: Local backup, network backup, and backup data to public clouds; DSM configuration backup, macOS Time Machine support, Cloud Station Backup Shared folder sync - maximum tasks: 16
·
FTP Server: Bandwidth control for TCP connections, custom FTP passive port range, anonymous FTP, FTP SSL/TLS and SFTP protocol, boot over the network with TFTP and PXE support, transfer logs
·
High Availability Manager: Reduce service downtime by setting up two identical NAS into one high-availability cluster
·
Security Advisor: Malware detection/removal, user account/password, network, system-related security scan
·
Supported Clients: Windows 7 or above, Mac OS X 10.10 or above
·
Power Consumption: 142.76 W (Access), 55.05 W (HDD Hibernation)
·
Certifications: EAC, VCCI, CCC, RCM, FCC, CE, BSMI
·
Dimensions (WxDxH): 430.5 x 692.0 x 88.0 mm
·
Weight: 14.5 kg
·
Package Contents: Main Unit, Accessory Pack, AC Power Cord, Quick Installation Guide
·RoHS Compliant
