The Pro Channel III is a fully-featured channel strip with selectable mic impedance, two compression voicings, and semi-parametric EQ. New to this version, the compressor has both Tube/Opto and FET modes for smooth or punchy dynamic control. The compressor and EQ sections can now be reordered at the touch of a button, and the front panel has been streamlined for a faster, simpler workflow. The mic preamp features a discrete FET input stage and up to 60 dB of preamp gain, with a variable low cut filter to eliminate rumble and tighten bass.
The EQ section offers a switchable low shelf frequency, variable low-mid and high-mid frequencies with over 4 octaves of range per band, and a 12 kHz high shelf. The Pro Channel III is also a versatile instrument DI. Connecting to the front 1/4" input will override the rear XLR input so you can record direct tracks without disconnecting your mic or line signal.
Designed for recording musicians seeking a versatile character preamp with real tube warmth, the Pro Channel III offers the flexibility and fidelity to sculpt and enhance any source.
Features* Class A FET Microphone Preamp
* Selectable Microphone Impedance
* 1/4" High Z Input on Front Panel
* Compressor and EQ Sections with Switchable Order and Independent Bypass
* Tube/Opto and FET Compressor Voicings
* 4-Band Semi-Parametric EQ and Variable Low Cut Filter
* Insert Point after Preamp Stage
* +4 dBu or -10 dBv Operation
* Universal Internal Power Supply
Specifications- Frequency Response: 12 Hz - 100 kHz (+0, -1 dB)
- Dynamic Range: 110 dB A-Weighted
- CMRR: 90 dB
- THD: 0.009% (Typical @ 1k)
- Equivalent Input Noise: -128 dBu (Mic / Line), -109 dBu (Instrument), Input Short, Max Gain, A-Weighted
- Maximum Input Level: +22 dBu (+4 dBu Mode), +13 dBu (-10 dBV Mode) Balanced
- Maximum Insert Input Level: +22 dBu (+4 dBu Mode), +13 dBu (-10 dBV Mode) Unbalanced
- Maximum Instrument Input Level: +23 dBu (+4 dBu Mode), +14 dBu (-10 dBV mode) Unbalanced
- Input Impedance: 600Ω / 47 kΩ (XLR), > 800 kΩ (Instrument), 7.5 kΩ (Insert)
- Maximum Output Level: +26 dBu (Balanced), +20 dBu (Unbalanced)
- Output Impedance: 47Ω (XLR)
- Maximum Gain: 40 dB Variable Input Gain, 20 dB Switchable Boost, 15 dB Variable Output Gain, +75 dB Total
- Low Cut Filter: 10 Hz - 250 Hz (Single Pole)
- Compressor Attack: 0.25 ms 100 ms
- Compressor Release: 0.1 s 3 s
- Compressor Ratio: 1.25:1 - 20:1
- Parametric EQ: 40 Hz / 120 Hz (Low), 20 Hz - 2 kHz (Lo-Mid), 200 Hz - 20 kHz (Hi-Mid), 12 kHz (High)
- Power Requirements: 100 - 240 V 50 Hz / 60 Hz 25 W
- Dimensions: 3.5" x 19" x 9.2" (8.9 x 48.3 x 23.3 cm)
- Weight: 10.5 lbs (4.76 kg)
