About: DS18 8XL800N-8 XL Series 8" Neodymium Magnet Mid-Range Loudspeaker 400W RMS - 8 Ohm (Each)
8” Mid-Range Loudspeaker With Neodymium Magnet | 8-ohm
The 8XL800N-8 is designed to deliver mind-blowing clarity, making it the go-to choice for high-performance car audio systems. With an impressive power handling of 400W RMS and 800W MAX, you can reach extreme volumes while maintaining your audio’s integrity.
Precision-Tuned Frequency Response
With a wide frequency response range of 100Hz – 10kHz, the 8XL800N-8 captures every detail of your favorite tracks. Delivering perfectly balanced sound across the midrange spectrum.
Extreme Sensitivity for Maximum Output
With an insane 100.7dB sensitivity rating, this speaker produces incredibly high SPL (Sound Pressure Levels) with less power. It maximizes output without distortion, ensuring louder, clearer sound even in large vehicles and open spaces.
Advanced Engineering for Superior Durability
The 2” Kapton voice coil provides exceptional heat resistance, allowing the speaker to handle extended play at high power levels without overheating. The non-pressed paper cone enhances audio accuracy and responsiveness, while the cloth surround ensures durability and smooth performance—even under extreme conditions.
Lightweight Yet Powerful Neodymium Magnet
The 8XL800N-8 utilizes a lightweight yet incredibly powerful 7.5oz neodymium magnet. This high-strength magnetic system enhances speaker efficiency, ensuring tighter, punchier midrange frequencies with minimal distortion.
Optimized for Versatile System Integration
Designed with a 8-ohm impedance, the 8XL800N-8 is highly versatile and integrates seamlessly into multi-speaker configurations. Its push-terminal connectors ensure secure and hassle-free installation, making it the perfect choice for custom audio builds.
If you’re looking to crank up the volume without sacrificing clarity, DS18’s 8XL800N-8 is the perfect addition to your sound system.
Product Highlights:
8" Mid-Range
MAX Power: 800 Watts
RMS Power: 400 Watts
Impedance: 8-Ohm
Neodymium Magnet
100.7dB
Specifications:
SKU: 8XL800N-8
Nominal Diameter: 8" / 203mm
Nominal Impedance: 8 ohms
RMS Power Handling: 400 watts
MAX Power Handling: 800 watts
Interleaved Sandwich Voice Coil (ISV): No
Demodulating Rings: Yes
Improved Heat Dissipation: Yes
Cone Shape: Curvilinear
Speaker Terminals: Push 12ga
Motor:
Voice Coil Diameter: 2" / 50.8mm
Voice Coil Former Material: Kapton
Winding Material: CCAW
Cone Material: Non-pressed Paper
Dust Cap Material: Paper
Bullet Material: N/A
Bullet Color/Finish: N/A
Surround Material: Cloth
Spider Diameter: 5" / 127mm
Leads Type: Direct to Cone
Basket Material: Aluminum
Basket Color/Finish: Satin Black
Magnet Material: Neodymium
Magnet Weight: 7.5 Oz
Displacement Volume: 0.03L / 0.00105ft3
Thiele & Small Parameters:
Equivalent Volume Vas: 17.09L / 0.603ft3
Excursion (one way) Xmax: 2.3mm
Free Air Resonance Fs: 87Hz
Mechanical Factor Qms: 5.68
Electrical Factor Qes: 0.27
Total Factor Qts: 0.26
Mechanical Mass Mms: 12.66g
Mechanical Compliance Cms: 0.26mm/N
BL Factor BL: 12
Voice Coil Inductance Le: 0.06mH
Cone Area Sd: 213.82cm2
DC Resistance Re: 5.6 ohm
Mechanical Mass w/o air Mmd: 11g
Measurements:
Overall Diameter: 8.2" / 210mm
Overall Depth: 3.85" / 98mm
Front Mount Baffle Cutout: 7.2" / 183mm
Mounting Depth: 3.38" / 86mm
Motor Diameter: 4" / 102mm
