Specifications
·
Mfr Part Number: FD-C-MES2C-02
·
Features:
·Iconic angular mesh front provides filtered airflow with a bold, stealth-inspired aesthetic
·Room for GPUs up to 360 mm with a 240 mm radiator in the top, or up to 360/280 mm front radiators with GPUs under 305 mm
·Install up to 7x 120 mm or 4x 140 mm fans (1x 120 mm and 2x 140 mm Dynamic X2 fans included)
·Versatile and space-efficient ATX form-factor design offers the performance and capacity of much larger cases
·Open interior layout creates a smooth airflow path from front intake to rear exhaust
·Seamlessly integrated TG panel with steel frame support and bolt-free top-latching mechanism
·Fully removable top panel and top fan bracket opens to provide excellent interior access and easy cable routing
·Three front USB ports including one USB 3.1 Gen 2 Type-C with fast charging and speeds up to 10Gbps
·Robust cooling capacity with seven fan positions and support for up to 360/280 mm radiators
·Flexible storage options supporting two 2.5€/3.5€ drives and up to four SSDs (two SSD brackets included)
·New front nylon filter that can be removed for increased airflow
·Easy-to-clean filters on the front, top and base with full PSU coverage and convenient front access
·Improved cable routing with three integrated cable alignment clips and six velcro straps
·Full length power supply shroud with two-part removable cover conceals drive cage and excess cabling for smooth airflow and a clean interior
·Seven bridgeless expansion slots ensure obstruction-free connections
·
Color: Black
·
Drive Bays:
·
3.5"/2.5" drive mounts: 2 (included)
·
Dedicated 2.5" drive mounts: 4 (2 included)
·
5.25€ drive mounts: 0
·
Expansion Slots: 7
·
Motherboard compatibility: ATX / mATX / Mini-ITX
·
Power supply type: ATX
·
Front interface: 1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, Reset button
·
Fan Options:
·
Total fan mounts: 7x 120 or 4x 140 mm and 2x 120 mm
·
Front: 3x 120 or 2x 140 mm, (2x Dynamic X2 GP-14 included)
·
Top: 2x 120/140 mm
·
Rear: 1x 120 mm, (1x Dynamic X2 GP-12 included)
·
Bottom: 1x 120 mm (requires removal of HDD cage)
·
Dust filters: Top, front and bottom
·
Radiator Options:
·
Front: Up to 360/280 mm
·
Top: Up to 240 mm
·
Rear: 120 mm
·
Bottom: 120 mm (requires removal of HDD cage)
·
Cable routing space: 17-28 mm
·
Cable routing grommets: Yes
·
Fixed velcro straps: Yes
·
Tool-less push-to-lock: Top, front and side panels
·
Captive thumbscrews: HDD, SSD and PSU brackets
·
Left side panel: Tempered Glass
·
Right side panel: Steel
·
Dimensions & Weight:
·
PSU Max Length: 200 mm (165 mm with HDD cage and front fan)
·
GPU Max Length: 341 mm (360 mm without front fan)
·
CPU Cooler Max Height: 169 mm
·
Case Dimensions (LxWxH):424 x 210 x 475 mm; 412 x 210 x 455 mm w/o feet/protrusions/screws
·
Net Weight: 8.1 kg
·
Package Dimensions (LxWxH): 542 x 320 x 554 mm
·
Gross Weight: 9.8 kg
·
Package Contents:
·€‹Meshify 2 Compact Case
·User manual
·Accessory box
·
UPC-BarCode: 843276102333
