TALKBOX SYNTH offers classic and new sounds to the guitarist's arsenal. From instantly recognizable talkbox "hose-in-the-mouth" sounds to wonderfully electronic "talking robot" effects, imagine yourself commanding attention at jams and gigs. Even when the effect is off, TALKBOX SYNTH can vastly improve your core vocal sound with Adaptive Tone, reverb and pitch correction.
Classic talkbox effects have always come through a PA, not a guitar amp, so TALKBOX SYNTH is the ideal way to bridge that gap. The XLR output of TALKBOX SYNTH sends your polished vocal mic output to the PA while also outputting the on-board effects when you hit the foot switch. The guitar input and output circuitry is designed to preserve your precious guitar tone as it passes to your pedals and amplifier.
GUITAR TO SYNTH TRANSFORMED
The on-board synthesizer is triggered by your single note guitar playing and can translate your solos and licks into something even a skilled keyboardist would marvel at. The nuances of finger vibrato combined with your vocal expression take your guitar solos and licks from earthbound to mile high in an instant.
YOUR PERSONAL SOUND TECH
Adaptive EQ (equalization), compression, de-ess, and gate automatically control the timbre and shape of your vocal, ensuring that every note you sing is clean and clear. Because when the crowd can hear what you're singing, they can sing along and there is nothing is better than that!
With transparent auto-chromatic pitch correction, Talkbox Synth nudges your pitch to the nearest semitone. It won't turn a potato into a spaceship, but it can give you a little support when you need it most.
STUDIO GRADE REVERB
Reverb simulates a physical space, allowing your voice to fit into the music perfectly. Whether its the ambiance of a small room, or the massive reverberation of a concert hall, TalkBox Synth's vocally tuned reverb always brings out the best in your voice.
FEATURE SUMMARY
Modern and Classic Talk Box styles
4 Synth styles
Talk Box effects with or without Guitar thru
Reverb (Room, Studio, Hall)
Tone button for Adaptive EQ, Compression, De-essing and Gating
Battery operation (batteries optional)
Auto Chromatic Pitch Correction
Easy connection between standard mic and mixer
Phantom power always available
Low noise microphone pre-amp
Automatic input gain no more setting and adjusting input gain
Mic Control for remote on/off switching with optional TC-Helicon MP-75, MP-76 (main button only) and Sennheiser e835 FX mics
Rugged all-metal construction
USB connection to VoiceSupport application offering updates, product-specific news and more
9V operation to accommodate common pedalboard power supplies
SPECS:
Effects
- Guitar Talk Box and Vocoder
- Synth Vocoder
- Reverb
- Pitch Correction
- Adaptive Tone
Control
- Guitar Talk Box and Vocoder effects with or without guitar thru
- Selection of 4 Synth Vocoder waveforms
- Correction amount 0 to 100%
- 3 vocally tuned Reverb styles with adjustable level
- Adaptive Tone on/off
- Mic Control on/off
- Footswitch on/off
Design
Mic In to Out
Input Connector: XLR female, balanced
Input Impedance: 3k1 Ohm
Input Clip Sensitivity: -1 dBu
SNR A-Weighted: > 114 dB
Phantom Power: 24V (always on)
Output Connector: XLR male, impedance balanced, pin 2 hot
Output impedance: 200 Ohm
Output Full Scale Level: +7.5 dBu
Input to Output Frequency Response: +0/-0.3 dB, 20 Hz to 20 kHz
Guitar In to Guitar Thru
Input Impedance: 1 MOhm
Guitar Input Level @ 0 dBFS: -7 dBU to 17 dBu
Dynamic Range: > 117 dB, 20 Hz to 20 kHz
Physical
- Height: 5.4 inches (140 mm)
- Width: 3.5 inches (90 mm)
- Depth: 2.3 inches (60 mm)
- Weight: 0.92 lb. (0.42 kg)
- Two-part die cast metal
- Rubber adhesive feet
Power
Power Supply (Not Included): 9V 670mA
Power Consumption: 6W
