饾棧饾椏饾椉饾棻饾槀饾棸饾榿 饾棗饾棽饾榾饾棸饾椏饾椂饾椊饾榿饾椂饾椉饾椈
路 Thickened Steel
Withstand Heavy Pressure Without Deformation
路 Stable Base
Stable and Shake-Resistant Under Pressure
路 Quality Assurance
Durable and Heavy-Duty
路 Durable Construction
Built with a thick steel frame for strong load-bearing and deformation resistance, this press features a powder-coated surface for both durability and corrosion resistance.
路 Non-Slip Column
The shop press鈥檚 heavy-duty downward column ensures long-term use without slipping or deformation, paired with an ergonomic handle for effortless operation.
路 Movable Plates
This hydraulic shop press features two movable, flat stamping plates, which allows for flexible fixation of different-sized parts, making operations easier.
饾棪饾椊饾棽饾棸饾椂饾棾饾椂饾棸饾棶饾榿饾椂饾椉饾椈饾榾
Item Model Number: ZX0901 item 30T
Product Dimensions: 33.6 脳 27.4 脳 68.9 in/855脳700脳1750 mm
Cylinder Stroke: 4.9 in/125 mm
Rated Load: 30T
Hydraulic Pump Operating Pressure: 0.8-1.2 MPa
Hydraulic Oil Model: 15#
Net Weight: 249.7 lbs/113.25kg(Include all accessories)
饾棧饾棶饾棸饾椄饾棶饾棿饾棽 饾棖饾椉饾椈饾榿饾棽饾椈饾榿
1 x 30T Pressure Gauge
1 x Seal Washer (pre-installed on oil cylinder component)
1 x Oil Cylinder Component
1 x Tapered End Tightening Screw M8脳8 (pre-installed on oil cylinder component)
1 x Upper Cap (pre-installed on oil cylinder component)
1 x Piston (pre-installed on oil cylinder component)
4 x Hex Bolt M8脳16
2 x Cross Beam
8 x Hex Bolt M16脳35
8 x Flat Washer 蠁16
8 x Spring Washer 蠁16
8 x Hex Nut M16
2 x Vertical Column
1 x Oil Cylinder Mounting Plate Welded Assembly
1 x Lower Cap (pre-installed on oil cylinder component)
16 x Flat Washer 蠁10
16 x Spring Washer 蠁10
12 x Hex Nut M10
2 x Pressure Block
4 x Workbench Support Pipe
2 x Workbench
2 x Cotter Pin
4 x Hex Bolt M10脳170
10 x Hex Bolt M10脳25
4 x Diagonal Brace
4 x Hex Bolt M12脳30
2 x Angle Iron
1 x Connecting Rod Component
4 x Flat Washer 蠁12
4 x Spring Washer 蠁12
4 x Hex Nut M12
1 x Handle
2 x Hex Bolt M10脳20
1 x Pneumatic Quick Connect Hose (American-style)
1 x Pneumatic Manual Pump Component
1 x Oil Hose Component
1 x User Manual
1 x European-style Quick Connect Fitting
路 30 Ton Strong Load Capacity: Our hydraulic press helps you easily disassemble and install automotive bushings, ball joints, U-joints, and more, as well as straighten, bend, and stamp metal parts. Whether you're a professional or a DIY car repair enthusiast, it allows for quick and simple operation.
路 Hydraulic and Pneumatic: This hydraulic shop press features a pneumatic assist pump that connects quickly to an air compressor for easier operation. Includes a security regulator valve to avoid overloading and safeguard against bending or damage.
路 Adjustable Height: The hydraulic shop press鈥檚 worktable features a quick-adjust pin system with 8 height settings, ranging from 2.6 to 36.9 inches (65-938 mm), providing flexible working positions. The cylinder stroke is 4.9 inches (125 mm). Note: Exceeding the cylinder stroke range may cause damage to the cylinder seals.
路 Triangular Base Reinforcement: Upgraded with a triangular brace, the hydraulic shop press鈥檚 triangular structure significantly enhances base stability. Combined with the H-shaped frame, the press remains steady and wobbling-resistant during the operation of fastening components.
路 Heavy-Duty Construction: Built with thickened steel, this structure offers enhanced weight-bearing capacity and durability. The large-diameter pressure column is designed to minimize slipping, ensuring sturdiness and long-lasting performance, even under heavy use.
