AT A GLANCE ImagingSensor Resolution Actual: 13.4 Megapixel (4268 x 3148), Effective: 8.29 Megapixel (3840 x 2160)Sensor Type 1" CMOS SensorImage Stabilization Optical in Integrated Lens DigitalBuilt-In ND Filter Mechanical Filter Wheel with 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND FiltersShutter Type Rolling ShutterShutter Speed 1/4 to 1/2000 secShutter Angle 11 to 360°Sensitivity f/12 at 2000 luxMinimum Illumination 1.5 Lux at 1/30 Shutter SpeedWhite Balance 2000 to 15,000KLensFocal Length 8.3 to 124.5mm (35mm Equivalent Focal Length: 25.5 to 382.5mm)Optical Zoom Ratio 15xMax Digital Zoom 30x ( in 1080p)Maximum Aperture f/2.8Minimum Aperture f/4.5Optical Design 18 Elements in 14 GroupsMinimum Focus Distance Entire Zoom Range: 2.0' / 60.0 cm, Wide: 0.4" / 1.0 cmFilter Size 58 mmControl Rings Focus, Zoom, IrisFocus Control Autofocus, Manual FocusRecordingRecording ModesMXF/XF-AVC 4:2:2 10-Bit:
3840 x 2160p at 23.98/25/29.97/50/59.94 fps (160 to 410 Mb/s)
1920 x 1080p at 23.98/25/29.97/30/50/59.94/120 fps (50 to 310 Mb/s)
1920 x 1080i at 50/59.94 fps (50 to 160 Mb/s)
1280 x 720p at 23.98/25/29.97/30/50/59.94 fps
H.265/MP4 4:2:2 10-Bit:
3840 x 2160p at 23.98/25/29.97/50/59.94 fps (135 to 225 Mb/s)
1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps (50 Mb/s)
1280 x 720p at 23.98/25/29.97/50/59.94 fps (12 Mb/s)
H.265/MP4 4:2:0 10-Bit:
3840 x 2160p at 23.98/25/29.97/50/59.94 fps (100 to 170 Mb/s)
1920 x 1080p at 23.98/25/29.97/50/59.94 fps (35 Mb/s)
1280 x 720p at 23.98/25/29.97/50/59.94 fps (9 Mb/s)
H.264/MP4 4:2:0 8-Bit:
3840 x 2160p at 23.98/25/29.97/50/59.94 fps (150 Mb/s)
1920 x 1080p at 23.98/25/29.97/50/59.94 fps (35 Mb/s)
1280 x 720p at 50/59.94 fps Variable Frame Rates to 120 fpsGamma Curve Canon Log 3, HDR-HLGAudio Recording 2-Channel 16-Bit 48 kHz AAC Audio, 4-Channel 24-Bit 48 kHz LPCM AudioIP Streaming MPEG2: 1920 x 1080 to 3840 x 2160 at 25p, 29.97p, 50p, 59.94p (4.0 to 16.00 Mb/s), MPEG2: 1920 x 1080 to 1920 x 1080 at 50i, 59.94i (4.0 to 9.0 Mb/s)InterfaceMedia/Memory Card Slot Slot 1: SD/SDHC/SDXC, Slot 2: SD/SDHC/SDXCVideo Connectors 1 x HDMI (HDMI 2.0) Output, 1 x BNC (12G-SDI) OutputAudio Connectors 2 x 3-Pin XLR Input, 1 x 1/8" / 3.5 mm Stereo Input, 1 x 1/8" / 3.5 mm Stereo Headphone OutputBuilt-In Microphone Type StereoOther I/O
·1 x USB Type-A Output
·
·1 x USB Type-C
·
·1 x BNC Genlock, Sync Input/Output
·
·1 x BNC Timecode Input/Output
·
·1 x 2.5 mm Control
·
·1 x 8-Pin D-Sub Control
·
·1 x RJ45 LAN Input/Output
·Wireless Interfaces 2.4 / 5 GHz MIMO Wi-Fi Video Output, Audio Output, ControlMonitor Size 3.45"Resolution 2,760,000 DotDisplay Type Articulating Touchscreen LCDEVFEVF AttachedEVF Display Type OLEDScreen Size .36"EVF Resolution 1,770,000 DotsPowerBattery Type Canon BP-A SeriesPower Connectors 1 x Barrel (24 VDC) InputPower Consumption 21.5 W
